浮式生产储油卸油装置单点系泊系统综述

谢锏辉, 杨料荃

  1. 深圳海油工程水下技术有限公司,广东 深圳 518067
  • 收稿日期:2014-08-20 出版日期:2014-09-20 发布日期:2016-03-30
  • 作者简介:

    作者简介:谢锏辉(1987--),男,硕士,主要从事水下结构物和单点锚系的研究.

Review of Single-Point Mooring System of FPSO

Jian-hui XIE, Liao-quan YANG

  1. COOEC Subsea Technology Co.,Ltd., Shenzhen, Guangdong 518067,China
  • Received:2014-08-20 Online:2014-09-20 Published:2016-03-30

RichHTML

0

PDF (PC)

344

摘要：

针对国内浮式生产储油卸油装置FPSO单点系泊系统进行了系统的综述.分别介绍了悬链式系泊系统(CALM),单锚腿系泊系统(SALM),塔式软刚臂系泊系统(SYS),外转塔式系泊系统(ETM)和内转塔式系泊系统(ITM),并展望了FPSO在我国深水海洋油气资源开发中的应用.

关键词: 浮式生产储油卸油装置, 单点系泊系统, 软刚臂系泊系统, 内转塔系泊系统

Abstract:

We summarize the single-point mooring systems of floating production storage and offloading system (FPSO). The review covers catenary anchor leg mooring system, single anchor leg mooring, soft yoke mooring system, external turret mooring system, and internal turret mooring system. In the end, the application prospects of FPSO for domestic deepwater oil and gas resources development are given.

Key words: floating production storage and offloading system, single-point mooring system, soft yoke mooring system, internal turret mooring system
