| Design of CBTC System Simulation Laboratory for Urban Rail Transit |
Yibo CUI1( ), Yibo JIAO2, Wang SUN1, Zhuangfeng WANG1 |
1. Signal &Communication Research Institute, China Academy of Railway Sciences,Beijing 100081, China
2. School of Computer and Information Technology,Beijing Jiaotong University, Beijing 100044, China |
|
|
|
|
Abstract A construction scheme for urban rail transit CBTC system simulation laboratory was designed. The CBTC system consists of various subsystems, so it is highly integrated and has much equipment. According to the construction scheme, we built subsystems firstly and then integrated the whole system. Each subsystem can run the simulation experiment independently, and some experiments can also be completed by the whole system. Through reasonable planning, a complete CBTC system simulation environment was built in one laboratory. The scheme ensures the integrity of the whole CBTC system, and the integration of the equipment in the same laboratory also reduces the occupied area and reduces the cost of laboratory construction. It also provides reference for the similar laboratory construction.
|
|
