Abstract

Spectroscopic technology is widely used for analysis of hydrocarbon inclusions, but previous studies showed some limits of single spectroscopic method. We proposed multi-spectroscopic technology to analyze hydrocarbon inclusions in reservoirs, which combines with fluorescence spectrum, Raman spectrum, and infra-red spectrum. This method can make up shortage of single spectrum technology. This paper reported that multi-spectrum was used to study the maturity of oil in hydrocarbon inclusions from reservoir of Huo-Ma-Tu structure belt in southern Zhungaer basin. The results indicate that multi-spectrum can not only be a complementation for single spectrum, but also give more reliable information about maturity of oil in hydrocarbon inclusions.

Key words： multi-spectroscopy fluorescence spectrum infra-red spectrum Raman spectrum hydrocarbon inclusions

Received: 08 September 2016 Published: 10 July 2017

ZTFLH:

P571

	Service

	E-mail this article
	Add to my bookshelf
	Add to citation manager
	E-mail Alert
	RSS
	Articles by authors
	Yong CHEN
	Mengjun ZHAO
	Qingong ZHUO
	Shaobo LIU
	Xintao WANG

Cite this article:

Yong CHEN,Mengjun ZHAO,Qingong ZHUO, et al. Determining Maturity of Oil in Hydrocarbon Inclusions by Multi-spectroscopy[J]. Research and Exploration in Laboratory, 2017, 36(5): 14-16.

URL:

http://www.qk.sjtu.edu.cn/rel/EN/ OR http://www.qk.sjtu.edu.cn/rel/EN/Y2017/V36/I5/14

[1]	刘德汉,卢焕章,肖贤明. 油气包裹体及其在石油勘探和开发中的应用[M]. 广州:广东科技出版社,2007:196-201.
[2]	潘长春,周中毅,解启来.油气和含油气包裹体及其在油气地质地球化学研究中的意义[J].沉积学报,1996,14(4):15-23.
[3]	Liu Keyu, Xiao Xianming, Mills D, et al.Cautions in the interpretation of petroleum fluid inclusion data in petroleum system analysis: Insight from spectroscopic analyses of natural and synthetic inclusions[J]. Journal of Geochemical Exploration, 2009, 101: 62.
[4]	赵艳军,陈红汉.油包裹体荧光颜色及其成熟度关系[J].地球科学,2008,33(1):91-96.
[5]	George S C, Ruble T E, Dutkiewicz A, et al.Assessing the maturity of oil trapped in fluid inclusions using molecular geochemistry data and visually-determined fluorescence colours[J]. Applied Geochemistry, 2001, 16: 451-473.
[6]	Goldstein R H,Reynolds T J.Systematics of fluid inclusions in diagenetic minerals[J]. SEPM Short Course, 1994,31: 199.
[7]	Barres O, Burneau A, Dubessy J, et al.Application of Micro-FT-IR Spectroscopy to Individual Hydrocarbon Fluid Inclusion Analysis[J]. Applied Spectroscopy, 1987, 41(6): 1000-1008.
[8]	李荣西,金奎励,廖永胜.有机包裹体显微傅立叶红外光谱和荧光光谱测定及其意义[J]. 地球化学,1998,27(3):244-250.
[9]	邹育良,霍秋立,俞萱. 油气包裹体的显微红外光谱测试技术及应用矿物岩石[J]. 地球化学通报,2006,25(1):105-108.
[10]	孙青,翁诗甫,张煦. 傅立叶变换红外光谱分析矿物有机包裹体的限制-基体吸收问题初探[J]. 地球科学,1998,23(3):248-252.
[11]	Pironon J,Thiery R,Aytougougdal M,et al. FT-IR measurements of petroleum fluid inclusions:methane,n-alkanes,and carbon dioxide quantitative analysis[J]. Geofluids,2001(1):2-10.
[12]	张鼐,宋孚庆,王汇彤.石油中饱合烃类的喇曼特征[J].矿物岩石地球化学通报,2006,25(1):33-36.
[13]	张鼐,田作基,冷莹莹,等. 烃和烃类包裹体的拉曼特征[J]. 中国科学(D辑),2007,37(7):900-907.
[14]	魏东涛,贾东,赵应成,等. 准噶尔盆地南缘白垩系原油成藏特征[J].地质论评,2008,54(3):145-155.
[15]	Matthias Radke.Application of aromatic compounds as maturity indicators in source rocks and crude oils[J]. Marine and Petroleum Geology, 1988(5): 224-236.
