Paradrenal anastomosing hemangioma: a case report with literature review

doi:10.16150/j.1671-2870.2022.06.12

Abstract

Abstract:

Objective: This paper reported 1 case of paradrenal anastomosing hemangioma (AH), and to summarize the clinicopathological features, diagnosis and differential diagnosis of AH. Methods: The clinical data of this patient was collected, the histological morphology and immunohistochemical characteristics were observed and analyzed in combination with relevant literature. Results: The tumor was located in the adipose tissue around the adrenal gland, it was well circumscribed, gray and red colored. Microscopically, the tumor was composed of irregularly anastomosing sinusoidal-like spaces lined by hobnail endothelial cells, focal mild atypia was observed. Intravascular fibrin thrombi and hyaline globules could be seen. Immunohistochemical results showed diffuse staining for endothelial markers, including CD31 and CD34. D2-40, CK5/6, calretinin, CKpan, EMA, Melan-A and HMB45 immunostains were negative. Ki-67 staining indicated a low proliferative activity. Eventually this patient was diagnosed with AH. Conclusions: AH is a rare but distinct type of vascular neoplasm. Owing to its striking anastomosing appearance, it needs to be distinguished from well differentiated angiosarcoma. In addition, the differential diagnosis of urogenital AH also includes angiomyolipoma, adenomatoid tumor, and hemangiomatoid hyperplasia secondary to renal cell carcinoma.

Key words: Adrenal gland, Anastomosing hemangioma, Immunohistochemical feature

CLC Number:

R692.39

YAN Huaru, LIU Kun, HAN Zhihong, FANG Zhen, WU Lili. Paradrenal anastomosing hemangioma: a case report with literature review[J]. Journal of Diagnostics Concepts & Practice, 2022, 21(06): 735-740.

Figures/Tables 4

文献	例数（n）	性别	年龄（岁）	部位	最大径（cm）	术前诊断	处理	随访
O′Neill AC et al^[15]	32	18男 14女	17~81	腹膜后；肾脏；主动脉旁；肾旁；卵巢；肝脏；睾丸；肾上腺；肠系膜；精索	不详	肾上腺嗜铬细胞瘤；肠系膜脂肪肉瘤；肾癌；腹膜后脂肪肉瘤；淋巴结伴癌转移；其余未知	肿块切除术；粗针穿刺活检	4例2~26个月无复发或转移。其余失访。
John I，et al^[14]	16	10男 6女	2~85	主动脉旁；椎体；腰大肌；胸椎旁；脊椎旁；腹膜后；纵隔漏斗状骨盆韧带；子宫角；上臂；下腔静脉旁和右主动脉旁	1.5~6.7 4例不详	肉瘤；周围神经鞘瘤和淋巴瘤；其余未知	9例肿块切除术；7例粗针穿刺活检	10例1~46个月无复发转移或疾病进展。其余失访。
Bean GR, et al^[19]	13	9男 4女	39~70	肾；肾上腺；脊柱；椎旁；下腔静脉旁；腹膜；卵巢；附件旁；子宫肌层；肝脏	0.7~8.0	未知	肿块切除术	10例1~107个月无复发或转移。其余失访。
Kryvenko ON， et al^[17]	7	1男 7女	39~77	肾（其中一例为双侧）；卵巢	0.6~5.0	卵巢子宫内膜样癌；卵巢浆液囊肿；卵巢浆液性囊腺瘤；其余因其它疾病行CT检查发现肾脏肿块	肿块切除术	10例随访3~122个月，无复发或转移。其余失访。
Montgomery E, et al^[1]	6	4男 2女	49~75	肾；睾丸	1.3~2.0	未知	3例肾切除术，1例肿块切除术，2例睾丸切除术	5例8~36个月无复发或转移。1例失访。
Lin J, et al^[4]	6	2男 4女	46~71	肝；结肠小肠	0.2~6.0	3血管瘤；3血管肉瘤	肿块切除术	5例8~96个月无复发或转移。1例失访。
赵明等^[9]	5	3男 2女	47~77	肾上腺；肾	1.6~2.5	肝癌肾转移；肾错构瘤；肾上腺嗜铬细胞瘤或皮质腺瘤	1例部分肾切除术，1例根治性肾切除术；3例肾上腺肿瘤切除术	5例6~52个月无复发或转移。
Burton KR, et al^[16]	1	男	68	多发：肾旁、下腔静脉旁、髂内、双侧肾上腺	1.5~3.7	肾恶性肿瘤	左肾上腺切除术、左肾周和下腔静脉旁结节切除术	未知
Huang ZY, et al^[10]	1	男	37	鼻腔	2.3	鼻息肉、乳头状瘤	肿块切除术	22个月无复发转移。
Ross M, et al^[2]	1	男	49	肾上腺	2.0	肾上腺肿瘤	肾上腺切除术	未知
Rathore K, et al^[11]	1	男	64	左心房	4.0	左心房壁肿瘤	肿块切除术	未知
姚建国等^[6]	1	男	71	肾上腺	1.7	右肾上腺肿瘤	右肾上腺切除术	10个月无复发转移。
虞义建等^[7]	1	男	50	肾上腺	1.1	嗜铬细胞瘤	右肾上腺切除术	未知
王小刚等^[8]	1	男	55	肾	4.0	左肾占位	根治性左肾切除术	12个月无复发转移。
党琳琳等^[5]	1	女	44	肝脏	5.0	富于血供的肿瘤	肿块切除术	2个月无复发转移。

References 22

[1]	Montgomery E, Epstein J I. Anastomosing hemangioma of the genitourinary tract: a lesion mimicking angiosarcoma[J]. Am J Surg Pathol, 2009, 33(9):1364-1369. doi: 10.1097/PAS.0b013e3181ad30a7 pmid: 19606014
[2]	Ross M, Polcari A, Picken M, et al. Anastomosing hemangioma arising from the adrenal gland[J]. Urology, 2012, 80(3):e27-e28. doi: 10.1016/j.urology.2012.05.032 URL
[3]	Kryvenko O N, Gupta N S, Meier F A, et al. Anastomosing hemangioma of the genitourinary system: eight cases in the kidney and ovary with immunohistochemical and ultrastructural analysis[J]. Am J Clin Pathol, 2011, 136(3):450-457. doi: 10.1309/AJCPJPW34QCQYTMT pmid: 21846922
[4]	Lin J, Bigge J, Ulbright T M, et al. Anastomosing hemangioma of the liver and gastrointestinal tract: an unusual variant histologically mimicking angiosarcoma[J]. Am J Surg Pathol, 2013, 37(11):1761-1765. doi: 10.1097/PAS.0b013e3182967e6c pmid: 23887160
[5]	党琳琳, 侯东省, 林存虎, 等. 肝吻合状血管瘤1例[J]. 临床与实验病理学杂志, 2020, 36(6):744-745.
	Dang L L, Hou D S, Lin C H, et al. Anastomotic hemangioma of liver: a case report[J]. Chin J Clin Exp Pathol, 2020, 36(6):744-745.
[6]	姚建国, 潘红佳, 王春华, 等. 吻合状血管瘤一例[J]. 中华病理学杂志, 2015, 44(2):133-134.
	Yao J G, Pan H J, Wang C H, et al. One case of anastomotic hemangioma[J]. Chin J Pathol, 2015, 44(2):133-134.
[7]	虞义建, 郑晶琼, 蒋武斌, 等. 原发肾上腺交织状血管瘤1例[J]. 临床与实验病理学杂志, 2020, 36(3):375-376.
	Yu Y J, Zhen J Q, Jiang W B, et al. One case of primary adrenal interlaced hemangioma[J]. Chin J Clin Exp Pathol, 2020, 36(3):375-376.
[8]	王小刚, 徐仁芳, 薛钟, 等. 肾吻合性血管瘤一例报告[J]. 中华泌尿外科杂志, 2019, 40(6):468.
	Wang X G, Xu R F, Xue Z, et al. Renal anastomotic hemangioma: a case report[J]. Chin J Urol, 2019, 40(6):468.
[9]	赵明, 孔梅, 余晶晶, 等. 肾脏及肾上腺交织状血管瘤临床病理分析[J]. 中华病理学杂志, 2016, 45(10):698-702. pmid: 27760611
	Zhao M, Kong M, Yu J J, et al. Clinicopathologic analysis of anastomosing hemangioma of the kidney and adrenal gland[J]. Chin J Pathol, 2016, 45(10):698-702. doi: 10.3760/cma.j.issn.0529-5807.2016.10.006 pmid: 27760611
[10]	Huang Z Y, Chen C C, Thingujam B. Anastomo-sing Hemangioma of the Nasal Cavity[J]. Laryngoscope, 2020, 130(2):354-357. doi: 10.1002/lary.v130.2 URL
[11]	Rathore K, Yussouf R, Teh M, et al. Left atrial anastomosing hemangioma causing recurrent pericardial effusion[J]. Ann Thorac Surg, 2020, 109(3):e157-e159. doi: 10.1016/j.athoracsur.2019.06.082 pmid: 31430463
[12]	Lappa E, Drakos E. Anastomosing Hemangioma: Short Review of a Benign Mimicker of Angiosarcoma[J]. Arch Pathol Lab Med, 2020, 144(2):240-244. doi: 10.5858/arpa.2018-0264-RS pmid: 30958692
[13]	Büttner M, Kufer V, Brunner K, et al. Benign mesenchymal tumours and tumour-like lesions in end-stage renal disease[J]. Histopathology, 2013, 62(2):229-236. doi: 10.1111/j.1365-2559.2012.04349.x pmid: 23020314
[14]	John I, Folpe A L. Anastomosing Hemangiomas Arising in Unusual Locations: A Clinicopathologic Study of 17 Soft Tissue Cases Showing a Predilection for the Paraspinal Region[J]. Am J Surg Pathol, 2016, 40(8):1084-1089. doi: 10.1097/PAS.0000000000000627 pmid: 26945338
[15]	O′neill A C, Craig J W, Silverman S G, et al. Anastomosing hemangiomas: locations of occurrence, imaging features, and diagnosis with percutaneous biopsy[J]. Abdom Radiol (NY), 2016, 41(7):1325-1332. doi: 10.1007/s00261-016-0690-2 pmid: 26960722
[16]	Burton K R, Jakate K, Pace K T, et al. A case of recurrent, multifocal anastomosing haemangiomas[J]. BMJ Case Rep, 2017, 2017:bcr2017220076.
[17]	Kryvenko O N, Roquero L, Gupta N S, et al. Low-grade clear cell renal cell carcinoma mimicking hemangioma of the kidney: a series of 4 cases[J]. Arch Pathol Lab Med, 2013, 137(2):251-254. doi: 10.5858/arpa.2011-0615-OA pmid: 23368867
[18]	Liau J Y, Lee J C, Tsai J H, et al. Thrombotic Hemangioma With Organizing/Anastomosing Features: Expanding the Spectrum of GNA-mutated Hemangiomas With a Predilection for the Skin of the Lower Abdominal Regions[J]. Am J Surg Pathol, 2020, 44(2):255-262. doi: 10.1097/PAS.0000000000001392 URL
[19]	Bean G R, Joseph N M, Gill R M, et al. Recurrent GNAQ mutations in anastomosing hemangiomas[J]. Mod Pathol, 2017, 30(5):722-727. doi: 10.1038/modpathol.2016.234 URL
[20]	Liau J Y, Lee J C, Tsai J H, et al. High frequency of GNA14, GNAQ, and GNA11 mutations in cherry hemangioma: a histopathological and molecular study of 85 cases indicating GNA14 as the most commonly mutated gene in vascular neoplasms[J]. Mod Pathol, 2019, 32(11):1657-1665. doi: 10.1038/s41379-019-0284-y URL
[21]	Liau J Y, Tsai J H, Lan J, et al. GNA11 joins GNAQ and GNA14 as a recurrently mutated gene in anastomo-sing hemangioma[J]. Virchows Arch, 2020, 476(3):475-481. doi: 10.1007/s00428-019-02673-y
[22]	Sahni V A, LY A, Silverman S G. Usefulness of percutaneous biopsy in diagnosing benign renal masses that mimic malignancy[J]. Abdom Imaging, 2011, 36(1):91-101. doi: 10.1007/s00261-009-9597-5 pmid: 20049430

第一作者	例数（n）	边界	吻合的小血管	靴钉样内皮细胞	细胞不典型性	核分裂	CD31/ CD34	微小血栓	嗜酸性小体	髓外造血	变性
John I, et al^[14]	16	1/16局灶不清	16/16+	16/16+	轻	少-无	+	16/16+	未知	7/16+	未知
Bean GR, et al^[15]	13	2/13局灶不清	13/13+	6/13+	轻-无	少-无	未知	13/13+	12/13+	7/13+	7/13+
Kryvenko ON, et al^[17]	7	清楚	7/7+	3/7+	无	无	+	未知	6/7+	3/17+	4/7+
Montgomery E, et al^[1]	6	3/6局灶浸润	6/6+	6/6+	轻-无	少-无	+	5/6+	2/6+	2/6+	5/6+
Lin J, et al^[4]	6	清楚	6/6+	6/6+	轻	无	3/3+	4/6+	1/6+	1/6+	未知
赵明等^[9]	5	清楚	5/5+	5/5+	无	少-无	+	+	1/5+	2/5+	5/5+
Huang ZY, et al^[10]	1	清楚	+	+	轻	无	+	未知	未知	无	未知
姚建国等^[6]	1	清楚	+	+	轻	未知	+	+	未知	未知+	+
虞义建等^[7]	1	清楚	+	+	无	无	+	+	未知	未知	未知
党琳琳等^[5]	1	欠清楚	+	+	轻	无	+	+	未知	未知	+
