Screening and pathway analysis of autophagy-related genes in Alzheimer disease

doi:10.16138/j.1673-6087.2024.04.04

Abstract

Abstract:

Objective Screen autophagy related genes of Alzheimer disease(AD) based on microarray analysis, conduct pathway analysis and identify key genes in order to explore potential pathogenesis and therapeutic targets. Methods The GSE33000 dataset was downloaded from GEO Database, and the differentially expressed genes of AD were obtained by R software limma package. Autophagy-related genes were downloaded from Human Autophagy Database, Human Autophagy Modulator Database and GeneCard Database, respectively, and the autophagy-related gene set was obtained. The AD autophagy-related genes were obtained through intersecting the differentially expressed genes with the autophagy-related gene set. The R software packages such as org.Hs.eg.db and clusterProfiler were used to perform gene ontology (GO) analysis and Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis, the online software Search Tool for the Retrieval of Interacting Genes (STRING) was used to conduct protein-protein interaction network analysis, and the key genes were predicted based on MCC algorithm. Results A total of 66 autophagy related genes were obtained, of which 41 genes were up-regulated and 25 genes were down-regulated. Gene enrichment analysis showed that cellular components in GO analysis were mainly enriched in phagocytic vesicle membrane, secretory granule membrane, membrane microdomain, late endosome, etc., and molecular functions were mainly enriched in Toll-like receptor binding, ubiquitin-like protein ligase binding, etc., and biological processes were enriched in regulation of autophagy, positive regulation of cellular catabolic process, response to lipopolysaccharide, regulation of inflammatory response, cellular response to external stimulus, etc. In KEGG enrichment analysis, the differentially expressed autophagy-related genes were mainly concentrated in NOD-like receptor signaling pathway, lipid and atherosclerosis, forkhead box protein O(FoxO) signaling pathway, etc. Our research completed the construction of protein-protein interaction (PPI), identified 10 key genes, and screened out that interleukin-6(IL-6) and signal transducer and activator of transcription 3(STAT3) were closely related to AD. Conclusions Ten key autophagy-related genes were obtained in this study, among which IL-6 and STAT3 are more closely related to AD.

Key words: Alzheimer disease, Autophagy, Genes, Bioinformatics

CLC Number:

R749.1

SHENG Zhaoqing, LIU Xiaohong. Screening and pathway analysis of autophagy-related genes in Alzheimer disease[J]. Journal of Internal Medicine Concepts & Practice, 2024, 19(04): 236-242.

Figures/Tables 11

Figure 1

Table 1

Differentially expressed ARG

基因	log₂FC	FDR	上调/下调
S100A8	0.734 430 653	1.294 75E-41	上调
S100A9	0.631 580 392	2.997 15E-41	上调
GFAP	0.609 292 049	4.453 38E-55	上调
BAG3	0.446 585 26	5.753 08E-48	上调
SPP1	0.419 081 46	2.439 46E-40	上调
DDIT4	0.387 251 516	5.005 39E-49	上调
CDKN1A	0.368 832 806	2.884 3E-44	上调
NFKBIA	0.363 802 97	8.647 81E-75	上调
IL6	0.359 681 502	3.796 82E-17	上调
CCL2	0.345 877 034	7.361 13E-31	上调
GJA4	0.334 011 564	1.492 26E-45	上调
TNFRSF10B	0.309 289 337	2.784 55E-69	上调
PDK4	0.283 985 514	1.619 89E-26	上调
CEBPB	0.282 784 748	4.097 13E-59	上调
CXCR4	0.274 577 193	4.684 29E-34	上调
TREM2	0.274 073 704	2.786 42E-35	上调
SERPINH1	0.270 492 92	3.114 4E-31	上调
CASP1	0.263 382 958	9.255 49E-51	上调
HMOX1	0.256 356 446	1.288 31E-36	上调
CASP4	0.253 136 162	1.349 79E-51	上调
IL10RA	0.252 086 766	7.222 95E-48	上调
TRIM22	0.251 133 782	6.561 9E-55	上调
VAMP8	0.249 623 31	9.593 4E-50	上调
MYD88	0.249 228 915	1.156 73E-51	上调
LAMP2	0.247 986 568	4.413 14E-40	上调
KDR	0.242 699 838	1.689 45E-17	上调
CYBB	0.241 577 351	1.078 61E-28	上调
ITGB4	0.236 962 537	1.708 02E-47	上调
NFE2L2	0.231 527 954	2.941 17E-59	上调
MCL1	0.231 458 541	1.725 39E-52	上调
DCN	0.228 229 134	2.220 71E-29	上调
RELA	0.224 802 04	1.358 85E-59	上调
SLC1A5	0.223 657 939	4.543 77E-50	上调
ITPR3	0.221 584 092	1.796 88E-42	上调
TCIRG1	0.219 778 682	5.358 93E-53	上调
PLCE1	0.219 757 497	5.667 72E-65	上调
NFKBIZ	0.217 692 335	1.087 39E-40	上调
MYC	0.213 477 663	2.334 41E-36	上调
NDRG1	0.211 367 782	2.057 29E-33	上调
LGALS3	0.209 718 41	1.968 45E-29	上调
STAT3	0.206 894 233	1.137 87E-56	上调
DUSP4	-0.499 845 019	1.766 41E-60	下调
CAMK4	-0.494 161 901	2.063 21E-74	下调
BDNF	-0.477 357 958	5.418 81E-81	下调
PAK1	-0.469 712 144	1.555 31E-70	下调
IGF1	-0.392 947 702	1.648 13E-67	下调
TBC1D9	-0.331 515 013	4.391 44E-54	下调
MAP2K1	-0.279 448 405	2.363 26E-32	下调
PLK2	-0.278 443 738	1.786 23E-46	下调
HSPA8	-0.255 422 758	6.227 56E-28	下调
GABBR2	-0.235 543 436	1.284 5E-48	下调
CAMKK2	-0.235 461 651	1.826 4E-67	下调
PRNP	-0.234 526 608	7.010 57E-35	下调
RALB	-0.231 614 543	3.131 96E-43	下调
MAPK8	-0.229 246 562	1.221 77E-29	下调
VDAC1	-0.229 196 778	4.274 23E-51	下调
SNCA	-0.226 627 217	2.682 88E-54	下调
HIVEP2	-0.225 398 91	2.151 41E-42	下调
KIAA1524	-0.224 809 135	1.178 74E-36	下调
CDKN2D	-0.221 703 258	1.496 62E-79	下调
GABARAPL1	-0.214 767 25	7.058 2E-60	下调
PIK3CB	-0.213 074 216	7.147 73E-27	下调
VDAC2	-0.210 329 444	7.610 65E-52	下调
FBXL2	-0.208 120 876	1.005 31E-49	下调
NRG3	-0.205 871 654	1.082 04E-42	下调
TBC1D7	-0.204 288 881	2.941 05E-43	下调

Table 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Table 2

References 31

[1]	Scheltens P, De Strooper B, Kivipelto M, et al. Alzheimer’s disease[J]. Lancet, 2021, 397(10284):1577-1590. doi: 10.1016/S0140-6736(20)32205-4 pmid: 33667416
[2]	王刚, 齐金蕾, 刘馨雅, 等. 中国阿尔茨海默病报告2024[J]. 诊断学理论与实践, 2024, 23(3):219-256.
[3]	Levine B, Kroemer G. Autophagy in the pathogenesis of disease[J]. Cell, 2008, 132(1):27-42. doi: 10.1016/j.cell.2007.12.018 pmid: 18191218
[4]	Pickford F, Masliah E, Britschgi M, et al. The autophagy-related protein beclin 1 shows reduced expression in early Alzheimer disease and regulates amyloid beta accumulation in mice[J]. J Clin Invest, 2008, 118(6):2190-2199. doi: 10.1172/JCI33585 pmid: 18497889
[5]	Nixon RA, Wegiel J, Kumar A, et al. Extensive involvement of autophagy in Alzheimer disease: an immuno-electron microscopy study[J]. J Neuropathol Exp Neurol, 2005, 64(2):113-122.
[6]	Yu WH, Cuervo AM, Kumar A, et al. Macroautophagy-a novel β-amyloid peptide-generating pathway activated in Alzheimer’s disease[J]. J Cell Biol, 2005, 171(1):87-98.
[7]	Menzies FM, Fleming A, Caricasole A, et al. Autophagy and neurodegeneration: pathogenic mechanisms and therapeutic opportunities[J]. Neuron, 2017, 93(5):1015-1034. doi: S0896-6273(17)30046-6 pmid: 28279350
[8]	Nilsson P, Loganathan K, Sekiguchi M, et al. Aβ secretion and plaque formation depend on autophagy[J]. Cell Rep, 2013, 5(1):61-69. doi: 10.1016/j.celrep.2013.08.042 pmid: 24095740
[9]	Uddin MS, Mamun AA, Labu ZK, et al. Autophagic dysfunction in Alzheimer’s disease: cellular and molecular mechanistic approaches to halt Alzheimer’s pathogenesis[J]. J Cell Physiol, 2019, 234(6):8094-8112.
[10]	Motta V, Soares F, Sun T, et al. NOD-like receptors: versatile cytosolic sentinels[J]. Physiol Rev, 2015, 95(1):149-178. doi: 10.1152/physrev.00009.2014 pmid: 25540141
[11]	Jounai N, Kobiyama K, Shiina M, et al. NLRP4 negatively regulates autophagic processes through an association with beclin1[J]. J Immunol, 2011, 186(3):1646-1655. doi: 10.4049/jimmunol.1001654 pmid: 21209283
[12]	Zhang Y, Sauler M, Shinn AS, et al. Endothelial PINK1 mediates the protective effects of NLRP3 deficiency during lethal oxidant injury[J]. J Immunol, 2014, 192(11):5296-5304. doi: 10.4049/jimmunol.1400653 pmid: 24778451
[13]	Wlodarska M, Thaiss CA, Nowarski R, et al. NLRP6 inflammasome orchestrates the colonic host-microbial interface by regulating goblet cell mucus secretion[J]. Cell, 2014, 156(5):1045-1059. doi: 10.1016/j.cell.2014.01.026 pmid: 24581500
[14]	Chen Y, Zeng A, He S, et al. Autophagy-related genes in atherosclerosis[J]. J Healthc Eng, 2021,2021:6402206.
[15]	Shao BZ, Han BZ, Zeng YX, et al. The roles of macrophage autophagy in atherosclerosis[J]. Acta Pharmacol Sin, 2016, 37(2):150-156.
[16]	Menghini R, Casagrande V, Marino A, et al. MiR-216a: a link between endothelial dysfunction and autophagy[J]. Cell Death Dis, 2014, 5(1):e1029.
[17]	Li H, Huang S, Wang S, et al. Targeting annexin A7 by a small molecule suppressed the activity of phosphatidylcholine-specific phospholipase C in vascular endothelial cells and inhibited atherosclerosis in apolipoprotein E⁻/⁻mice[J]. Cell Death Dis, 2013, 4(9):e806.
[18]	Roher AE, Esh C, Kokjohn TA, et al. Circle of willis atherosclerosis is a risk factor for sporadic Alzheimer’s disease[J]. Arterioscler Thromb Vasc Biol, 2003, 23(11):2055-2062. doi: 10.1161/01.ATV.0000095973.42032.44 pmid: 14512367
[19]	Roher AE, Tyas SL, Maarouf CL, et al. Intracranial atherosclerosis as a contributing factor to Alzheimer’s disease dementia[J]. Alzheimers Dement, 2011, 7(4):436-444. doi: 10.1016/j.jalz.2010.08.228 pmid: 21388893
[20]	Arvanitakis Z, Capuano AW, Leurgans SE, et al. Relation of cerebral vessel disease to Alzheimer’s disease dementia and cognitive function in elderly people: a cross-sectional study[J]. Lancet Neurol, 2016, 15(9):934-943. doi: S1474-4422(16)30029-1 pmid: 27312738
[21]	Liu L, Tao Z, Zheng LD, et al. FoxO1 interacts with transcription factor EB and differentially regulates mitochondrial uncoupling proteins via autophagy in adipocytes[J]. Cell Death Discov, 2016,2:16066.
[22]	Wang S, Xia P, Huang G, et al. FoxO1-mediated autophagy is required for NK cell development and innate immunity[J]. Nat Commun, 2016,7:11023.
[23]	Baek SH, Kim KI. Epigenetic control of autophagy: nuclear events gain more attention[J]. Mol Cell, 2017, 65(5):781-785. doi: S1097-2765(16)30870-X pmid: 28257699
[24]	Hu F, Song D, Yan Y, et al. IL-6 regulates autophagy and chemotherapy resistance by promoting BECN1 phosphorylation[J]. Nat Commun, 2021, 12(1):3651. doi: 10.1038/s41467-021-23923-1 pmid: 34131122
[25]	Lyra E Silva NM, Gonçalves RA, Pascoal TA, et al. Pro-inflammatory interleukin-6 signaling links cognitive impairments and peripheral metabolic alterations in Alzheimer’s disease[J]. Transl Psychiatry, 2021, 11(1):251.
[26]	田密, 侯德仁, 邓炎尧, 等. STAT3与P-STAT3在转基因AD小鼠脑组织中的表达及意义[J]. 南方医科大学学报, 2013, 33(12):1778-1782.
[27]	You L, Wang Z, Li H, et al. The role of STAT3 in autophagy[J]. Autophagy, 2015, 11(5):729-739. doi: 10.1080/15548627.2015.1017192 pmid: 25951043
[28]	Reichenbach N, Delekate A, Plescher M, et al. Inhibition of Stat3-mediated astrogliosis ameliorates pathology in an Alzheimer’s disease model[J]. EMBO Mol Med, 2019, 11(2):e9665.
[29]	Choi M, Kim H, Yang EJ, et al. Inhibition of STAT3 phosphorylation attenuates impairments in learning and memory in 5XFAD mice, an animal model of Alzheimer’s disease[J]. J Pharmacol Sci, 2020, 143(4):290-299.
[30]	Sarkar S. Regulation of autophagy by mTOR-dependent and mTOR-independent pathways: autophagy dysfunction in neurodegenerative diseases and therapeutic application of autophagy enhancers[J]. Biochem Soc Trans, 2013, 41(5):1103-1130.
[31]	Schmukler E, Michaelson DM, Pinkas-Kramarski R. The interplay between apolipoprotein E4 and the autophagic-endocytic-lysosomal axis[J]. Mol Neurobiol, 2018, 55(8):6863-6880. doi: 10.1007/s12035-018-0892-4 pmid: 29353455

基因	英文全称	MCC评分
IL-6	interleukin 6	244 380
STAT3	signal transducer and activator of transcription 3	244 225
NFKBIA	nuclear factor-kappaB inhibitor alpha	213 723
MAPK8	mitogen-activated protein kinase 8	184 714
CCL2	CC chemokine ligand 2	169 968
MYC	myelocytomatosis viral oncogene homolog	136 967
HMOX1	heme oxygenase 1	108 768
RELA	v-rel reticuloendotheliosis viral oncogene homolog A (avian)	107 766
CASP1	caspase-1	106 712
NFE2L2	nuclear factor erythroid2-like-2	90 721
