The ultrasonic features and diagnostic performance of ultrasound for ovarian cystadenofibroma and adenofibroma

doi:10.16150/j.1671-2870.2021.02.008

Abstract

Abstract:

Objective: To investigate ultrasonic features of ovarian cystadenofibroma (CAF) and adenofibroma (AF). Methods: Ultrasonic features of 50 cases with ovarian CAF and 7 cases with AF were analyzed, and diagnostic performance of ultrasound was evaluated. Results: According to pathological findings of the CAF cases studied, 46 were benign CAF with 47 tumors identified, and 4 cases were borderline AF. All the seven AF cases were benign with single lesion. Pathologically, most of lesions was serous (53/58, 91.4%). With borderline CAF defined as malignant, the ultrasound differentiated benign from malignant masses of CAF and AF with a sensitivity of 100.0% (95%CI 39.8%-100.0%), specificity of 72.2% (95%CI 58.4%-83.5%), and accuracy of 74.1%. Most benign CAF masses were described as unilocular solid cysts (25/47, 53.2%) with regular morphology (43/47, 91.5%) and well-defined boundaries (46/47, 97.9%). Regular papillary projections (32/47, 68.1%) in CAF lesions manifested no or minimal color Doppler signals（31/32, 96.9%）. The borderline CAF masses were all identified with solid components or papillary projections, which manifested various degree of blood supply. Compared with benign CAF, borderline CAF showed more solid or papillary components [maximum diameter, borderline CAF was 19.5 (18.8-26.3) mm versus benign 8.0 (7.0-13) mm, P=0.002], with higher the maximum diameter ratio of the solid components or papillary projections to the mass [the borderline CAF was 0.35 versus benign CAF 0.15, P=0.033], and there were more blood supply inside the borderline CAF (4/4) than benign CAF (10/35), (P=0.012). Most of the AF masses were described as regular (6/7), well-defined (5/7) solid masses with shadowing identified (4/7). Absent color Doppler signals were recorded in the solid components (6/6). Conclusions: The ultrasound has a sound diagnostic performance for CAF and AF. Benign CAF lesions are mostly described as solid cysts with papillary projection(s) manifesting no or minimal color Doppler signals; borderline CAFs are mostly described as masses with papillary projection(s) and solid component(s) containing varied blood supply. AFs are mostly described as solid masses with shadowing identified and absent color Doppler signals. It is difficult to discriminate benign from borderline CAF, presence of solid components or papillary projections and copious blood supply may indicate borderline CAF.

Key words: Ovarian neoplasms, Ultrasonography, Cystadenofibroma, Adenofibroma

CLC Number:

R445.1

QIAN Le, JIANG Meijiao, YANG Bowen, CHEN Hui. The ultrasonic features and diagnostic performance of ultrasound for ovarian cystadenofibroma and adenofibroma[J]. Journal of Diagnostics Concepts & Practice, 2021, 20(02): 161-167.

Figures/Tables 6

References 21

[1]	Taylor EC, Irshaid L, Mathur M. Multimodality imaging approach to ovarian neoplasms with pathologic correlation[J]. Radiographics, 2021, 41(1):289-315. doi: 10.1148/rg.2021200086 pmid: 33186060
[2]	Cho SM, Byun JY, Rha SE, et al. CT and MRI findings of cystadenofibromas of the ovary[J]. Eur Radiol, 2004, 14(5):798-804. doi: 10.1007/s00330-003-2060-z URL
[3]	Czernobilsky B, Borenstein R, Lancet M. Cystadenofibroma of the ovary. A clinicopathologic study of 34 cases and comparison with serous cystadenoma[J]. Cancer, 1974, 34(6):1971-1981. pmid: 4434327
[4]	Kozawa E, Inoue K, Takahashi M, et al. Diffusion-weighted MR imaging findings of ovarian adenocarcinofibromas and adenofibromas[J]. Clin Imaging, 2014, 38(4):483-489. doi: 10.1016/j.clinimag.2014.01.014 URL
[5]	Timmerman D, Valentin L, Bourne TH, et al. Terms, de-finitions and measurements to describe the sonographic features of adnexal tumors: a consensus opinion from the International Ovarian Tumor Analysis(IOTA) Group[J]. Ultrasound Obstet Gynecol, 2000, 16(5):500-505. doi: 10.1046/j.1469-0705.2000.00287.x URL
[6]	Andreotti RF, Timmerman D, Strachowski LM, et al. ORADS US risk stratification and management system: a consensus guideline from the ACR Ovarian-Adnexal Reporting and Data System Committee[J]. Radiology, 2020, 294(1):168-185. doi: 10.1148/radiol.2019191150 pmid: 31687921
[7]	Tang YZ, Liyanage S, Narayanan P, et al. The MRI features of histologically proven ovarian cystadenofibromas-an assessment of the morphological and enhancement patterns[J]. Eur Radiol, 2013, 23(1):48-56. doi: 10.1007/s00330-012-2568-1 pmid: 22814827
[8]	潘玉萍, 蔡爱露, 赵丹, 等. 卵巢腺纤维瘤及囊性腺纤维瘤的超声特征[J]. 中国医学影像技术, 2012, 28(9):1699-1701.
[9]	Shimizu S, Okano H, Ishitani K, et al. Ovarian cystadenofibroma with solid nodular components masqueraded as ovarian cancer[J]. Arch Gynecol Obstet, 2009, 279(5):709-711. doi: 10.1007/s00404-008-0785-2 pmid: 18779972
[10]	徐健, 梅海炳, 高军, 等. 卵巢浆液性囊性腺纤维瘤MR诊断及病理分析[J]. 医学影像学杂志, 2016, 26(8):1494-1497.
[11]	Virgilio BA, de Blasis I, Sladkevicius P, et al. Imaging in gynecological disease(16): clinical and ultrasound cha-racteristics of serous cystadenofibromas in adnexa[J]. Ultrasound Obstet Gynecol, 2019, 54(6):823-830. doi: 10.1002/uog.20277 pmid: 30937992
[12]	Goldstein SR, Timor-Tritsch IE, Monteagudo A, et al. Cystadenofibromas: can transvaginal ultrasound appea-rance reduce some surgical interventions?[J]. J Clin Ultrasound, 2015, 43(6):393-396. doi: 10.1002/jcu.22241 pmid: 25271400
[13]	Landolfo C, Valentin L, Franchi D, et al. Differences in ultrasound features of papillations in unilocular-solid adnexal cysts: a retrospective international multicenter study[J]. Ultrasound Obstet Gynecol, 2018, 52(2):269-278. doi: 10.1002/uog.18951 pmid: 29119698
[14]	Timor-Tritsch IE, Yoon E, Monteagudo A, et al. Ultrasound and histopathologic correlation of ovarian cystadenofibromas: diagnostic value of the “shadow sign”[J]. J Ultrasound Med, 2019, 38(11):2973-2978. doi: 10.1002/jum.15003 pmid: 30927305
[15]	Zheng X, Lyu G, Gan Y, et al. Microcystic pattern and shadowing are independent predictors of ovarian borderline tumors and cystadenofibromas in ultrasound[J]. Eur Radiol, 2021, 31(1):45-54. doi: 10.1007/s00330-020-07113-z URL
[16]	Takeuchi M, Matsuzaki K, Harada M. Ovarian adenofibromas and cystadenofibromas: magnetic resonance ima-ging findings including diffusion-weighted imaging[J]. Acta Radiol, 2013, 54(2):231-236. doi: 10.1258/ar.2012.120516 pmid: 23171527
[17]	Jung DC, Kim SH, Kim SH. MR imaging findings of ovarian cystadenofibroma and cystadenocarcinofibroma: clues for the differential diagnosis[J]. Korean J Radiol, 2006, 7(3):199-204. doi: 10.3348/kjr.2006.7.3.199 URL
[18]	顾海磊, 唐文伟, 田忠甫, 等. 卵巢(囊)腺纤维瘤的磁共振成像诊断及鉴别[J]. 实用放射学杂志, 2020, 36(11):1798-1801.
[19]	Chen H, Liu Y, Shen LF, et al. Ovarian thecoma-fibroma groups: clinical and sonographic features with pathological comparison[J]. J Ovarian Res, 2016, 9(1):81. pmid: 27876070
[20]	Zhang Z, Wu Y, Gao J. CT diagnosis in the thecoma-fibroma group of the ovarian stromal tumors[J]. Cell Biochem Biophys, 2015, 71(2):937-943. doi: 10.1007/s12013-014-0288-7 URL
[21]	张慧娟. 卵巢交界性腺纤维瘤及囊腺纤维瘤的病理诊断[J]. 实用妇产科杂志, 2005, 21(10):586-588.

特征	良性CAF （46例）	AF （7例）	交界性CAF （4例）
年龄（岁）	48（33.3~58.0）	48（45.0~56.0）	38.5（29.0~56.0）
既往卵巢手术史	3（6.5%）	1	0
卵巢癌家族史或个人史	0/0	0/0	0/0
已绝经/未绝经	19/27	3/4	1/3
临床症状
腹痛、腹胀、腹围增大	10（21.7%）	0	0
腹部触及包块	10（21.7%）	2	0
阴道异常出血	2（4.3%）	1	0
体重明显改变	2（4.3%）	1	0
无明显症状	22（47.8%）	3	4
肿瘤指标 CA12-5>35 U/mL [n（%）]	5（10.9%）	0	1
CA12-5（U/mL）	12.3（10.1~18.7）	9.7（9.1~10.8）	21.2（15.7~205.1）
HE4>60.5 U/mL [n（%）]	7（15.2%）	0	0
HE4（U/mL）	38.0（32.9~47.1）	44.0（40.1~46.7）	41.2（36.0~43.1）

方法	良性CAF （n=47）	AF （n=7）	交界性CAF（n=4）
超声术前评估
良性	32（68.1%）	7	0
囊腺瘤或单纯性囊肿	20（42.6%）	3	/
系膜囊肿	6（12.8%）	0	/
内膜囊肿	3（6.4%）	0	/
AF	1（2.1%）	0	/
卵泡膜-纤维瘤类肿瘤	1（2.1%）	4	/
畸胎瘤	1（2.1%）	0	/
恶性或交界性	15（31.9%）	0	4
病理结果
浆液性	44（93.6%）	7	2
黏液性	2（4.3%）	0	0
内膜样	1（2.1%）	0	1
浆-黏液性	0（0.0%）	0	1

特征	良性CAF（n=47）	AF（n=7）	交界性CAF（n=4）
肿块位置
卵巢内	9（19.1%）	2	1
卵巢旁	16（34.0%）	2	1
无法辨别	22（46.8%）	3	2
肿块最大径（mm）	47（31~85）	33（24~70）	54.5（45~96）
肿块形态规则	43（91.5%）	6	2
肿块边界清晰	46（97.9）	5	2
肿块分类
单房囊性	4（8.5%）	0	0
单房囊实性	25（53.2%）	2	1
实性	2（4.3%）	4	1
多房囊性	8（17.0%）	1	0
多房囊实性	8（17.0%）	0	2
分隔厚度（mm）	2.3（1.9~3.3）	1.3	1.3/3.7
实性部分或乳头状突起	35（74.5%）	6	4
实性部分或乳头状突起最大径（mm）	8.0（7.0~13.0）	18.5（9.3~30.8）	19.5（18.8~26.3）^a)
实性部分或乳头状突起/肿块最大径比值	0.15（0.12~0.25）	1.00（0.46~1.00）	0.35（0.30~0.52）^b)
乳头状突起	32（68.1%）	2	3
1枚	13/32（40.6%）	0/2	0/3
2枚	3/32（9.4%）	0/2	0/3
3枚	5/32（15.6%）	1/2	0/3
≥4枚	11/32（34.4%）	1/2	3/3
乳头状突起最大径（mm）	7.5（7.0~11.3）	8/8	6/19/20
乳头状突起最大径/肿块最大径比值	0.15（0.12~0.22）	0.11,0.29	0.11,0.20,0.36
实性部分或乳头状突起血流评分
1分（无）	25/35（71.4%）	6/6	0/4^c)
2分（少量）	8/35（22.9%）	0/6	1/4
3分（中等）	2/35（5.7%）	0/6	2/4
4分（丰富）	0/35（0）	0/6	1/4
实性部分或乳头状突起后方回声衰减	15（31.9%）	4	1
肿块后方回声增强	27（57.4%）	3	2
