基于SimulationX的深水闸阀执行机构动态仿真研究

赵宏林1, 王鑫1, 肖玄1, 王珏2, 郭龙川1, 段梦兰1

  1. 1中国石油大学(北京)海洋油气研究中心,北京 102249
    2中海油研究总院,北京 100027
  • 收稿日期:2014-08-14 出版日期:2014-09-20 发布日期:2016-03-30
  • 作者简介:

    作者简介:赵宏林(1962--),男,教授,主要从事先进制造技术及石油装备方面的研究.

  • 基金资助:
    国家科技重大专项(2011ZX05026-003-01)

Dynamic Simulation Research on Deepwater Gate Valve Actuator Based on SimulationX

Hong-lin ZHAO1, Xin WANG1, Xuan XIAO1, Jue WANG2, Long-chuan GUO1, Meng-lan DUAN1

  1. 1Offshore Oil/Gas Research Center, China University of Petroleum, Beijing 102249, China
    2CNOOC Research Institute, Beijing 100027, China
  • Received:2014-08-14 Online:2014-09-20 Published:2016-03-30

RichHTML

3

PDF (PC)

223

摘要：

深水闸阀执行机构是控制深水闸阀开关状态的动力部件.一般采用液压控制的方式控制阀门开关.针对深水阀门执行机构特有的工况和结构特点,建立了包含导流孔阻尼影响在内的深水闸阀执行机构液压控制时的动力学模型,并且采用SimulationX软件进行了动态仿真.通过分析和比较仿真结果,验证了仿真的可行性,为研究深水闸阀执行机构的动态特性及其优化设计提供了参考依据.

关键词: 水下生产系统, 深水闸阀执行机构, 动态仿真, SimulationX

Abstract:

Deepwater gate valve actuator is the power component to control the switch of deepwater gate valve via a hydraulic way. On account of special working conditions and the structure characteristics of the deepwater gate valve actuator, the dynamical model of the deepwater gate valve actuator under the hydraulic control is established considering the damping effects of the flow guide hole, and the SimulationX software is used for dynamic simulation. By analyzing and comparing the simulation results, the feasibility of the simulation is verified. The results can provide reference for the optimization design and dynamic characteristics research of the deepwater gate valve actuator.

Key words: subsea production system, deepwater gate valve actuator, dynamic simulation, SimulationX
