Application of different tube voltage-current protocol in combination with KARL iterative reconstruction in CT chest scanning for novel coronavirus pneumonia screening

doi:10.16150/j.1671-2870.2020.02.016

Abstract

Abstract:

Objective: To explore application of different tube voltage-tube current scanning protocol in combination with KARL iterative reconstruction in CT chestscanning for coronavirus pneumonia screening. Methods: The study prospectively enrolled 120 patients with fever subjected to CT chest scanning, who were randomly assigned to groups exa-mined with different scanning protocols: 120 kV tube voltage and automatic tube current modulation with 60 mAs effective tube current (Group A); 120 kV tube voltage and 30 mA fixed tube current (Group B); 100 kV tube voltage and automatic tube current modulation with 60 mAs effective tube current (Group C); 100 kV tube voltage and 30 mA fixed tube current (Group D). The traditional FBP algorithm reconstruction and KARL iterative reconstruction were adopted in the study. The comprehensive image quality was evaluated subjectively based on noise and artifacts. Images reconstructed with FBP algorithm and KARL iterative reconstruction were compared by Wilcoxon test and Kruskal-Wallis test. The image noise within the regions of interest was measured, and the radiation dosage of each protocol in different groups was calculated. Radiation dosage and image noisefor each group were compared with t-test and ANOVA analysis. Results: The radiation dosage of group A, B, C, D were 2.5±0.4, 1.2±0.1, 1.6±0.2 and 0.8±0.1 mSv respectively. The lower tube voltage and tube current decreased the radiation dosage significantly (F=256.316, P<0.001). Image processed with KARL iterative reconstruction had lower noise and better subjective image quality than those treated with FBP reconstruction (P<0.05). At lower radiation dosage, the image acquired with tube voltage of 100 kV and a fixed tube current of 30 mA and processed by KARL iterative reconstruction achieved a score of 4.0 for overall subjective image quality. Conclusion: Compared with FBP reconstruction, KARL iterative reconstruction might reduce noise and improve image quality. With lower radiation dosage, the CT chest scanning protocol with a tube voltage of 100 kV and a fixed tube current of 30 mA in combination of KARL iterative reconstruction is optimum choice for novel coronavirus pneumonia screening.

Key words: Tomography, X-raycomputed, Iterativereconstruction, Imagequality, Radiationdosage

CLC Number:

R733.3

CHANG Rui, YANG Yanzhao, KONG Deyan, XU Jiaxu, CAO Qiqi, YANG Wenjie, YAN Fuhua, DONG Haipeng. Application of different tube voltage-current protocol in combination with KARL iterative reconstruction in CT chest scanning for novel coronavirus pneumonia screening[J]. Journal of Diagnostics Concepts & Practice, 2020, 19(02): 182-187.

Figures/Tables 5

References 11

[1]	中华人民共和国国家卫生健康委员会. 新型冠状病毒感染的肺炎诊疗方案(试行第七版)[EB/OL]. http://www.nhc.gov.cn/yzygj/s7653p/202003/46c9294a7dfe4cef80dc7f5912eb1989.shtml.
[2]	中华医学会放射学分会. 新型冠状病毒肺炎的放射学诊断:中华医学会放射学分会专家推荐意见(第一版)[J]. 中华放射学杂志, 2020, 54(4):278-285.
[3]	任法云, 付克广. 低剂量CT在肺结节筛查中的临床应用[J]. 中国医学计算机成像杂志, 2014, 20(5):389-393.
[4]	Singh S, Kalra MK, Gilman MD, et al. Adaptive statistical iterative reconstruction technique for radiation dose reduction in chest CT: a pilot study[J]. Radiology, 2011, 259(2):565-573. doi: 10.1148/radiol.11101450 URL
[5]	吴梦雄, 曹琪琪, 杨文洁, 等. 正弦图确定迭代重建在低剂量胸部CT筛查中的应用[J]. 诊断学理论与实践, 2017, 16(1):104-108.
[6]	张丽, 于红, 刘士远, 等. 迭代重建技术对低剂量肺部平扫CT图像质量的影响[J]. 中华放射学杂志, 2013, 47(4):316-321.
[7]	彭薇, 李琛玮, 杨利霞, 等. Karl迭代技术降低16层CT胸部扫描辐射剂量的水模和临床研究[J]. 放射学实践, 2015, 30(4):328-331.
[8]	袁知东, 刘鹏程, 王成林, 等. 噪声关联Z轴管电流调制技术降低多层CT胸部扫描辐射剂量的作用[J]. 中华放射学杂志, 2008, 42(11):1196-1200.
[9]	唐威, 黄遥, 吴宁, 等. 64层螺旋CT胸部低剂量扫描方案优选的多中心研究[J]. 中华放射学杂志, 2011, 45(2):142-148.
[10]	National Lung Screening Trial Research Team, Aberle DR, Berg CD, et al. The National Lung Screening Trial: overview and study design[J]. Radiology, 2011, 258(1):243-253. doi: 10.1148/radiol.10091808 URL
[11]	Larke FJ, Kruger RL, Cagnon CH, et al. Estimated radiation dose associated with low-dose chest CT of average-size participants in the National Lung Screening Trial[J]. Am J Roentgenol, 2011, 197(5):1165-1169. doi: 10.2214/AJR.11.6533 URL

组别	管电压	管电流	病例数（n）	年龄（岁）	身高（m）	体重（kg）	BMI（kg/m²）	DLP(mGy·cm)	ED（mSv）
A	120 kV	自动调控	30	43±15	1.65±0.1	62.0±10.2	22.6±3.1	182.6±31.5	2.5±0.4
B	120 kV	30 mA	30	49±19	1.67±0.1	63.4±11.9	22.6±3.5	88.5±6.6	1.2±0.1
C	100 kV	自动调控	30	41±15	1.66±0.1	62.8±12.5	22.6±3.4	114.7±17.7	1.6±0.2
D	100 kV	30 mA	30	44±18	1.69±0.1	64.4±11.2	22.5±3.0	55.6±3.0	0.8±0.1
F值	-	-	-	1.219	1.165	0.240	0.007	256.706	256.316
P值	-	-	-	0.306	0.326	0.868	0.999	<0.001	<0.001

重建方法	A组	B组	C组	D组	F值	P值
FBP	57.8±11.5	67.7±13.4	78.7±10.3	86.0±12.9	31.568	<0.001
KARL	43.4±8.0	48.1±7.7	58.9±6.4	61.6±9.8	34.915	<0.001
t值	16.135	11.866	14.696	14.819	-	-
P值	<0.001	<0.001	<0.001	<0.001	-	-

主观评分	FBP重建	KARL迭代重建	Z值	P值
图像噪声
A组	2.0(1.0)	1.0(0)	-4.119	<0.001
B组	2.0(0.25)	1.0(1.0)	-4.939	<0.001
C组	3.0(1.0)	2.0(1.0)	-5.014	<0.001
D组	3.5(1.0)	2.0(1.0)	-5.260	<0.001
χ²值	63.497	70.116
P值	<0.001	<0.001
伪影
A组	1.0(1.0)	1.0(0)	-2.449	0.014
B组	1.0(1.0)	1.0(0)	-3.162	0.002
C组	2.0(1.0)	1.0(0.25)	-4.000	<0.001
D组	2.0(0)	2.0(1.0)	-3.162	0.002
χ²值	41.073	40.906
P值	<0.001	<0.001
图像总体质量
A组	5.0(1.0)	5.0(0)	-2.714	0.007
B组	4.0(0)	5.0(0.25)	-4.359	<0.001
C组	4.0(0)	4.0(1.0)	-5.500	<0.001
D组	4.0(1.0)	4.0(0)	-4.000	<0.001
χ²值	37.191	36.149
P值	<0.001	<0.001
